Our mild steel pipe is produced on fully automatic imported plant from high-grade prime steel coil, and is drawn on for everything from fire-fighting mains to high-pressure steam lines. Every length is hydro-tested before it leaves the mill.

The range runs from 1/2" through 16" nominal bore in Schedule 10, 20, 40 and 80, and is available in both Grade A and Grade B to ASTM A53. Wall thickness runs to 12 mm, which is the ceiling the mill rolls to; heavier sections are supplied against order. Straightness, wall thickness, weight and length are all held to the standard, and mill test certificates are issued with every consignment.

Where a project calls for a specification other than ASTM — JIS, DIN, EN, BS, ISO or PS — we manufacture against it on enquiry.

Applications

Fire fighting
Water distribution lines
High pressure lines
Steam lines (boiler tubes, heat exchange tubes)
Hot and chilled water lines
Chemical liquid lines
Gas and oil projects

Sectors supplied

Cement
Power sector
Oil refineries
Sugar
Textile
Pharmaceutical

Specifications

Sizes and weights

Figures as published in our catalogue. Tolerances are held to the standard named on each table.

MS Pipe — Schedule 40 dimensions

ASTM A53

MS Pipe — Schedule 40 dimensions — ASTM A53
Nominal size in	Outside diameter		Wall thickness		Weight
Nominal size in	in	mm	in	mm	lb/ft	kg/m
1/8	0.405	10.3	0.068	1.73	0.24	0.37
1/4	0.540	13.7	0.088	2.24	0.42	0.63
1/2	0.840	21.3	0.109	2.77	0.85	1.27
3/4	1.050	26.7	0.113	2.87	1.13	1.69
1	1.315	33.4	0.133	3.38	1.68	2.50
1 1/4	1.660	42.2	0.140	3.56	2.27	3.39
1 1/2	1.900	48.3	0.145	3.68	2.72	4.05
2	2.375	60.3	0.154	3.91	3.65	5.44
2 1/2	2.875	73.0	0.203	5.16	5.79	8.63
3	3.500	88.9	0.216	5.49	7.58	11.29
3 1/2	4.000	101.6	0.226	5.74	9.11	13.57
4	4.500	114.3	0.237	6.02	10.79	16.07
5	5.563	141.3	0.258	6.55	14.62	21.77
6	6.625	168.3	0.280	7.11	18.97	28.26
8	8.625	219.1	0.322	8.18	28.55	42.55
10	10.750	273.0	0.365	9.27	40.48	60.31
12	12.750	323.8	0.406	10.31	53.52	79.73
14	14	355.6	0.437	11.13	63.44	94.55
16	16	406.4	0.500	12.70	82.77	123.30

Schedule 10, 20 and 80 available to the same standard, Grade A and Grade B. Wall thickness runs to 12 mm, which is what sets the top of this table — heavier walls are supplied against order.

Precision ERW Round Tube — mass in kg/m

BS 6323 Pt 1 & 5, BS 1717, ASTM A513, JIS G3445 STKM

Precision ERW Round Tube — mass in kg/m — BS 6323 Pt 1 & 5, BS 1717, ASTM A513, JIS G3445 STKM
Outside dia mm	Wall thickness — mass in kg/m
Outside dia mm	0.8	1.0	1.2	1.6	2.0	2.6	3.2
12.70	0.235	0.289	0.340	—	—	—	—
15.90	0.298	0.367	0.435	—	—	—	—
19.05	0.360	0.445	0.528	0.689	—	—	—
22.20	0.422	0.523	0.621	0.813	0.996	—	—
25.40	0.485	0.602	0.716	0.939	1.154	—	—
31.80	0.612	0.760	0.906	1.192	1.470	1.872	—
38.10	0.736	0.915	1.092	1.440	1.780	2.276	2.754
44.50	0.862	1.073	1.281	1.693	2.096	2.686	3.259
50.80	0.986	1.228	1.468	1.941	2.407	3.090	3.756
63.50	1.237	1.541	1.844	2.442	3.033	3.905	4.758
76.20	1.487	1.854	2.219	2.943	3.660	4.719	5.761

Light-wall mechanical and general-engineering tube, quoted on outside diameter. Heavier walls at each diameter are covered by the Schedule 40 chart on the MS Pipe page.
